Description

Enhanced Long-Term Reliability

The LG NeON 2 Black ACe has a 15 mm distance between the DC module and the Microinverter. The distance mitigates any impact to performance and reliability by allowing sufficient air-flow for cooling.

High Power Output

LG NeON 2 series modules produce high energy output from high-efficiency n-type cells, enabling more flexible use of available roof space.

Safer Solar Roof System

The LG NeON 2 Black ACe produces safe AC voltage and complies with NEC 2014 and 2017 standards.

User Friendly Monitoring

Remote Monitoring and Management with Enphase Enlighten software is featured. The LG NeON 2 Black ACe is easy to monitor and manage from any web-connected device.

Simplified Logistics

The LG NeON 2 Black ACe consolidates multiple PV system components into a single product SKU. This makes it easier to order, store and transport the modules.

Quick Installation

Installation of the LG NeON 2 Black ACe is a two-step process of lifting the inverter and connecting the cable without the need to install the inverter. This reduces installation labor requirements.

LG Solar > 320 Watt Black Frame NeON™2 Black ACe Solar Panel, with Enphase IQ6+ Micro Inverter

40mm Black Frame, White Backsheet with Enphase IQ6+ Microinverter.
60 Cell, high efficiency monocrystalline PV module.

Model	LG320E1K-A5
Series	NeON™2 Black ACe
Manufacturer	LG Solar

Mechanical

Type	Monocrystalline / N-type
Dimensions	66.4″ x 40″ x 1.6″
Weight	41.89 lbs
Frame	Black Anodized Aluminum
Inverter Model	Enphase IQ6+ Microinverter

DC Electrical Properties

Watts (STC)	320 W
Module Efficiency	18.7
Power Tolerance	0 ~ +3

AC Electrical Properties

Peak Output Power	290 V
Max. Continuous Output Power	280 V
Nominal Voltage / Range	240 / 211~264 V
Nominal Output Current	1.17 A
Nominal Frequency / Range	60.0 / 59.3~60.5 Hz
Power Factor / Adjustable	1 / 0.7leading…0.7lagging
CEC Weighted Efficiency	97.0%
Max. Branch Circuit Over Current Protection	20
Number of Max. AC Modules	13

Warranty

12 year product warranty – Solar Module
25 year product warranty – Micro Inverter
NEW Linear warranty*
1st year: 98%, 2) After 2nd year: 0.6%p annual degradation, 3) 83.6% for 25 years

Documentation

Data Sheet	LG Solar – LG-320E1K-A5
Installation Manual	LG Solar – PV Solar AC Module
Warranty	LG Solar

Detailed Information

The LG NeON® 2 Black ACe is embedded AC module, which combines LG NeON® 2 Black high power DC module and Enphase Micro inverter IQ6+. As they are combined, LG NeON® 2 Black ACe can simplify all the processes such as logistics, installation, and monitoring.

Features

High Power Output
The LG NeON® 2 series are proven to produce high energy output with top level efficiency. Unique high-efficiency n-type cell gives customer flexible use of roof space.
Simplified Logistics
Embedding micro inverter to LG NeON® 2 Black, PV system became one product. It gives people benefit of simple order, storage and transport.
Enhanced Long-term Reliability
The LG NeON® 2 Black ACe has 15mm AIR GAP between DC module and Micro inverter. The air gap cooling DC module and inverter down restricts decrease of performance by heats.
Safer Solar Roof System
The LG NeON® 2 Black ACe can be applied as safe system with low-voltage DC power system on roofs. Moreover, it conforms every norm for residential use such as NEC 2014 and 2017.
User Friendly Monitoring
“Enlighten” and “Installer’s tookit” monitoring system helps home monitoring and managing installation via web and mobile.
Quick Installation
When LG NeON® 2 Black ACe is installed on a roof, only two steps are needed: lifting and connecting. Therefore, LG NeON® 2 Black ACe can save the efforts and time for installation.
